Product description

The revolving and self-rotating mixing and defoaming machine can handle the mixing and deaerating of various materials with various viscosities and volumes. The materials are homogenized in a sealed negative pressure space without worrying about foreign matter being mixed in. The materials are pushed to the side wall of the container by the centrifugal force of the revolution, and the mixing is achieved due to the shear force generated between the side wall of the rotating container and the materials. 80 liters/minute, about -99kpa (relative to 0 meters above sea level), the combination of the revolution speed and the rotation speed, combined with the negative pressure system, can achieve the optimal mixing and defoaming of the materials in a short time.



Features
1.MT defoamer is a patented high-speed mixer mainly used for stirring liquid or powder materials and achieving defoaming effect at the same time, suitable for ultra-high viscosity materials;
2.The material is evacuated while rotating and revolving in the container, and the stirring, dispersion and defoaming of high-viscosity materials can be realized in 2-5 minutes;
3. It can store 10 sets of data (customizable), and each set of data can be divided into 5 segments to set different time, speed, and vacuum parameters to meet the stirring and defoaming requirements of most materials;
4. Equipped with different clamps and cups, it can stir materials within 1mL to 8000mL, easily meeting all requirements from experiments to mass production;
5.Single cup/double cup, vacuum optional;
6.Multi-parameters, multi-step operation; multiple safety protections, support customization.



Product Paramenters

Model

MT-P500

MT-P1400

MT-P3000

MT-P8000

Standard container

500mL*1

700mL*2

1500mL*2

4000mL*2 HDPE

Maximum speed

3000rpm

2800rpm

2500rpm

1200rpm

Maximum throughput

200mL*1

350mL*2

750mL*2

2000mL*2

Syringe handling capacity

5CC-10CC

5CC-50CC

5CC-960CC

5CC-960CC

Weight

90kg

180kg

240kg

700kg

Dimension

490*490*762(mm)

640*640*810(mm)

700*700*960(mm)

1100*1000*950(mm)

Revolution

Fixed speed ratio 1:0.8

(1:0-1:2) Revolution rotation ratio adjustable

Power

Maximum power consumption 1.7kw

Maximum power consumption 3.7kw

Maximum power consumption 12kw

Voltage

AC220-240V

AC380V three-phase

Vacuum pump power

750W

Vacuum pumping speed

20m³/H

Vacuum degree

0.1Kpa

Transfer method

Silent synchronous belt drive

Control System

Touch screen

Safety protection

Excessive vibration alarm、Work completion alarm prompt、Emergency stop key、Upper cover suppor 、Upper cover safety lock





Application
