V shape mixer are widely used in the efficient mixing of powdery and granular materials in pharmaceutical, chemical, food, light industry, electronics, machinery, mining and metallurgy, national defense industry and various scientific research units. The three-dimensional mixer is to eliminate the phenomenon of specific gravity segregation, stratification and accumulation caused by centrifugal force through the three-dimensional movement in the mixing cylinder space, so as to realize the mutual flow and diffusion among various materials, so as to achieve a rapid and uniform mixing of materials. At present, three-dimensional mixer is an advanced product with ideal performance in all aspects.

Description

The charging cylinder, driven by the main shaft, makes the compound motion such as translation, rotation and rolling, which urges the material to make three-way composite motion along the cylinder, so as to realize the mutual flow, diffusion, accumulation and doping of various materials, so as to achieve the purpose of uniform mixing. The multi-direction movement of the mixing cylinder, no centrifugal force of the material, incomparable gravity segregation and stratification, accumulation phenomenon, mixing rate of more than 99%, is a more ideal product in various mixers. The product has a large barrel loading rate, up to 90%(the ordinary mixer is only 40%), high efficiency and short mixing time. All parts of the cylinder are over-circular, after precision polishing treatment.

Feature

1.Compact structure, simple operation, smooth operation, no noise;

2.Suitable for mixing various materials, and the uniformity rate reaches 98%.

3.V-type mixer has better mixing effect when mixing frictional materials

4.Get better mixing effect when mixing materials with good fluidity and similar physical properties

5.Vacuum feeding and butterfly valve discharging can be implemented to achieve dust-free operation.

6.Adjustable forward and reverse rotation, panel control.

Parameters

Model	V-5L	V-10L	V-20L	V-50L	V-100L	V-200L	V-300L	V-500L	V-1000L
Capacity	5	10	20	50	100	200	300	500	1000
Useful capacity	≦50%
Load weight limit	Within 20kg	Within 20kg	Within 30kg	Within 30kg	30kg	60kg	90kg	150kg	300kg
RPM of main shaft（r/min）	13	13	13	13	15	15	15	13	10
Power (kw)	0.75	0.75	0.75	0.75	1.1	1.5	1.5	1.5	3
Voltage(v/hz)	220/50	220/50	220/50	220/50	380/50	380/50	380/50	380/50	380/50
Weight(kg)	120	120	120	120	150	260	320	550	950
