Powder 3D Mixing Machine
3D motion mixers are widely used in the efficient mixing of powdery and granular materials in pharmaceutical, chemical, food, light industry, electronics, machinery, mining and metallurgy, national defense industry and various scientific research units.
Category:
MIXING
Keywords:
Laboratory research equipment
Mixing Machine
Detailed
Not only does the design of high-value design, structure and system improve efficiency and performance more effectively, the application of noise control patent technology brings more comfortable and safe use experience
Industry annual statistics sales ranked first brand, users praise the first product
Application
3D motion mixers are widely used in the efficient mixing of powdery and granular materials in pharmaceutical, chemical, food, light industry, electronics, machinery, mining and metallurgy, national defense industry and various scientific research units. The 3D mixer is to eliminate the phenomenon of specific gravity segregation, stratification and accumulation caused by centrifugal force through the three-dimensional movement in the mixing cylinder space, so as to realize the mutual flow and diffusion among various materials, so as to achieve a rapid and uniform mixing of materials. At present, three-dimensional mixer is an advanced product with ideal performance in all aspects.
Summary
The charging cylinder, driven by the main shaft, makes the compound motion such as translation, rotation and rolling, which urges the material to make three-way composite motion along the cylinder, so as to realize the mutual flow, diffusion, accumulation and doping of various materials, so as to achieve the purpose of uniform mixing. The multi-direction movement of the mixing cylinder, no centrifugal force of the material, incomparable gravity segregation and stratification, accumulation phenomenon, mixing rate of more than 99%, is a more ideal product in various mixers. The product has a large barrel loading rate, up to 90%(the ordinary mixer is only 40%), high efficiency and short mixing time. All parts of the cylinder are over-circular, after precision polishing treatment.
Feature
1.The 3D mixer has a high loading rate of 80-90%(40-70%).
2.Compact structure of 3D moving mixer, convenient and intuitive loading and unloading.
3.High mixing uniformity, short mixing time and low energy consumption.
4.3D mixer stainless steel production, beautiful appearance, washable, easy for users to clear the field in mass production.
5. All parts of the three-dimensional mixer cylinder are over-circular arc, after multi-process precision polishing to achieve no dead angle, no hysteresis, easy discharge, easy cleaning.
6. Due to the multi-directional movement of the mixture cylinder, the material basically has no centrifugal force, and the phenomenon of extremely heavy segregation and delamination and accumulation.
7. The mixture ratio is over 99.9%, which is one of the most ideal products for mixer type.
8. Smooth, reliable, small vibration, easy operation and maintenance.
Parameter
|
Name |
Small experiment 3D mixer |
||
|
Model |
S-5L |
S-10L |
S-20L |
|
Capacity |
5L |
10L |
20L |
|
Available capacity |
50-70% of grinding tank |
||
|
Optimal mixing capacity |
Not less than 10% of grinding tank |
||
|
Load Weight Limits |
20kg |
||
|
Mixing time |
0-99H |
||
|
Suitable for mixing materials |
Powder |
||
|
Time Range |
0-99H |
||
|
Tube material |
304L |
||
|
Thickness of barrel |
2mm |
||
|
Thickness of seal plate |
1.5mm |
||
|
Support internal motor plate |
10mm |
||
|
Power |
1KW |
||
|
power of motor |
0.75KW |
||
|
Reduction box |
WPDA-70 |
||
|
Speed of main-shaft |
13 RPM |
||
|
Electrical protection grade |
3 grade |
||
|
self-aligning bearing |
UCP-35 |
||
|
Dimension |
800*800*800 |
||
|
Distance of outlet from ground |
350 |
||
|
Import and Export Dimensions |
110 |
||
|
driving mode |
Gear reducer direct transmission |
||
|
weight |
120KG |
130KG |
145KG |
